ZHAFIR VE400Ⅱ/80h 사출성형기 – Injection Molding Machine

사출성형기 ZHAFIR VE400Ⅱ/80h

출고일: 2020-08-31

주요 기술 사양:

• 형체력 (Clamping Force): 400 kN ≈ 40톤
• 스크류 직경 (Screw Diameter): Φ22 mm
• 사출 용량 (Injection Volume): 36 cm³ (≈ 30–35g/shot)
• 사출 압력 (Injection Pressure): 약 2000 bar (Φ22 기준 추정)
• 타이바 간격 (Tie-bar Distance): 252 × 230 mm
• 펌프 모터 출력 (Pump Motor Power): 15 kW
• 전원 (Power Supply): AC 380V, 3상, 50 Hz
• 정격 전류 (Rated Current): 26 A

생산 능력:

• 소형 사출성형기, 형체력 40톤 → 소형 금형, 고정밀 제품에 적합.
• 사출 용량 36 cm³ (30–35g/shot) → 대형 제품 사출 불가.

적용 분야 예시:

• 전자 부품: 잭, 커넥터, 소켓.
• 소형 엔지니어링 플라스틱: 기어, 케이스, 정밀 플라스틱 부품.
• 소형 얇은 제품: 버튼, 생활용 플라스틱 부품

ZHAFIR VE400Ⅱ/80h Injection Molding Machine

Date of Manufacture: 2020-08-31

⚙️ Main Technical Specifications

• Clamping Force: 400 kN ≈ 40 tons
• Screw Diameter: Φ22 mm
• Injection Volume: 36 cm³ (≈ 30–35g/shot)
• Injection Pressure: ~2000 bar (estimated for Φ22)
• Tie-bar Distance: 252 × 230 mm
• Pump Motor Power: 15 kW
• Power Supply: AC 380V, 3-phase, 50 Hz
• Rated Current: 26 A

🔎 Production Capability Assessment

• Small-size injection molding machine, clamping force 40 tons → suitable for small molds and high-precision parts.
• Injection volume 36 cm³ (30–35g/shot) → not suitable for large-size products.

Typical Applications:

• Electronic components: jacks, connectors, sockets.
• Small engineering plastics: gears, housings, precision plastic parts.
• Small thin-walled products: buttons, daily-use plastic accessories.
